Under Cover

Product priceConsultation required
Product information차량 하부에 부착되어 운행시 지면의 이물질로부터 차체를 보호하는 기능의 부품
TAG#Engine bottom cover #Under Cover #GMT
Product packaging and Shipping conditions Packaging & Shipping
7kgs/Pallet or Carton Box.

Contact Supplier

Contacts

김현중
010-9448-1791
jjang258@idongsung.com

Contact supplier

Related Products

Rear-Bumper

Rear Bumper

차량 후미에 부착되어 충돌 시 충격흡수를 하기 위한 부품
Guard-1

Guard

운전석 및 탑승자를 보호하는 기능의 부품
80_1-1

Rail Skirt

측면 낙석 등으로부터 적재함을 보호하는 역할을 하는 부품
Tool-Box

Tool Box

트럭 적재함 하단부에 부착되는 공구박스

적용차종

HMC : UNIVERSE

KMC : GRANBIRD

HMC : MEGA TRUCK

Product Description

GMT(Glass fiber Mat reinforced Thermoplastics)

  • It is called reinforced thermoplastic plastic and made by reinforcing polypropylene resin and Glass Fabric mat. It is 20-25% lighter than iron while having the strength of steel and widely used as an iron alternative.

< Reliability Test >

Test item Test method Unit Category Test result Test standards
Heat resistance cycle property MS 213-51 – 1 No layer separation, swelling, deformation. There shall be no layer separation, swelling, deformation
Moisture resistance MS 213-51 – 1 No layer separation, swelling, deformation There shall be no layer separation, swelling, deformation
Oil resistance MS 213-51 – 1 ENGINE OIL BREAK FLUID T/M OIL

POWER STEERTING OIL

WIND SHIELD WASHER liquid antifreeze liquid

 No layer separation, cracks, blisters, swelling There shall be no layer separation, swelling, deformation
Low-temperature impact resistance MS 213-51 – 1 No crack There should be no CRACK

< Material report >

Maker Hyundai motor company Project ASTM D2584-11
Supplier Hanwha Advanced Material Co., Ltd. Part NO. ASTM D792-13(A Method)
HKMC EO NO. – MS Name (MS NO.) PP-UNDER COVER ASSEMSLY(MS213-51 TYPE S)
HKMC EO REV. (Date) – MS REV NO. (DATE) 14th (2018.06.18)
MS total Test item number 12 Number of Test Items / Regulated value 0,000 units Item Numbers 12 / 12
Material / Grade MT-GF30 / StrongtLite RD 30 / Hanwha Advanced Material
Test Period 2018.07.02 ~ 2018.07.27 Production Date (LOT NO,) 2018.07.02 (201807-02)
Test Purpose Regular Test Sample
Type		 □  PROTO (Prototype)

□  PILOT (Pilot Product)

■  PRODUCT (Mass-produced)

Supply Ability

  • Process: Heating → Press → Trimming → Assembly
  • Lead Time : 1 day

Packing & Delivery

  • Packaging Details : 7kgs
